PT60 Digital Airspeed Sensor - APM Pixhawk Pitot Tube

The PT60 Digital Airspeed Sensor is equipped with the MPXV7002 series piezoresistive transducer, which is housed in a small outline package (SOP). This sensor is specifically designed to cater to a broad spectrum of applications, especially those that involve the use of microcontrollers or microprocessors with A/D inputs.By employing advanced micromachining techniques, thin-film metallization, and bipolar processing, this cutting-edge monolithic silicon pressure sensor delivers a precise, high-level analog output signal that corresponds to the pressure applied.The MPXV7002 is engineered to register both positive and negative pressure. It features a unique offset specifically at 2.5V, as opposed to the traditional 0V, enabling this series to measure pressures up to 7kPa from each port for pressure sensing and vacuum detection. For more detailed information, please refer to the transfer function in the datasheet.

Features:

• Pressure Range: ±2 kPa (±0.3 psi)
• Output: 0.5 - 4.5 V
• Digital differential pressure sensor with I2C communication
• Sensor Configuration: Upper port for pressure, lower port for static pressure

Specifications:

• Airspeed Module Dimensions: 21mm x 20mm x 10mm
• Pitot Tube Dimensions: 110mm x 9.8mm
• Weight: 25g

Package Contents:

• 1 x PT60 Pitot Tube
• 1 x 4525D Digital Module
